Dini Argeo

DFW ATEX 3GD - Zone 2 / 22 ATEX Indicator

Weight indicator for areas classified as hazardous with protection methods according to:
• II 3G Ex nR IIC T6 X
• II 3D Ex tD A22 IP68 T130°C X.
Ideal for creating weighing systems, batching, and automation systems. CE-M approvable (OIML R-76 / EN 45501).

£662.00 £794.40

  • Waterproof 16-key functional keypad.
  • LCD display with 6 25-mm high contrast digits and with indication of active functions.
  • Satined IP68 stainless steel case.
  • Up to 10.000e or multirange 3 x 3000e @ 0,3 µV/d for CE-M approved legal for trade use.
  • Up to 800,000 displayable divisions for internal factory use.
  • Up to 8 signal linearization points with DINITOOLS (3 from keypad).
  • Internal resolution up to 3.000.000 points.
  • A/D 24-bit sigma-delta conversion, up to 200 conv./sec. autoselect.
  • Board protection case inside the box.
  • Digital calibration and set-up from keyboard.
  • Instrument management & configuration from PC with DINITOOLS.
  • 4 channels (for single weighing system).
  • Connection with up to 8 load cells with 350 Ohm input resistance
For other options please see data sheet
For all options not listed on the options list, please call 0800 915 4201

More Information
CommunicationRS232, RS485, Ethernet, Wireless RF, 4-20ma / 0 - 10v
ATEX ZoneZone 2, Zone 22
DisplayLCD display with 6 x 25mm high contrast digits
Power Requirements110-240 Vac power supply with internal power adapter or battery option
IP RatingIP68
