Dini Argeo

DGT20 Process Weighing Indicator

Multipurpose weight transmitter ideal for the production of bench or floor scales, dosage, filling systems etc. The wide range of available interfaces, makes it easy to integrate the weighing with any automation system.
£360.00 £432.00

Main Features

Easy to use 5-key waterproof keyboard.
Highly efficient red LED display with 6 20-mm digits and 6 LEDs for showing active functions.
Aluminium/painted steel protective case, dimensions 170x115x68mm, fitted with support bracket (168x150mm) for table or wall mounting.
Calibration, Set-Up parameters, configurable from keyboard or from PC with DINI TOOLS.
Up to 1.000.000 displayable divisions with internal resolution up to 3.000.000 points.
Up to 8 signal linearization points with DINITOOLS (3 from keypad).
A/D 24-bit sigma-delta conversion, up to 200 conv./sec. autoselect.
Connectable with up to 16 analogue load cells with 350 Ohm input resistance.
Management of a digitally equalised 4-cell weighing system or management of 4 independent weighing systems.
From 12 Vdc to 24 Vdc power supply; 12Vdc power adapter included.


Zeroing; Semi automatic and presettable tare, print and/or data transmission; ON/Stand-by.

High Resolution Weighing x 10; Net/Gross or lb/kg conversion; Weighs totalisation; Formulation; Counting; In/Out Truck weighing; Hold e Peak.

Simulation of key pressure; Keyboard lock.

Set Point Control on the weight, either positive (in loading) or negative (in unloading), or on the pieces (counting mode), with programmable enabling/disabling thresholds, as direct check or upon weight stability.

On all models: Reading of the net, gross, and tare weights; Clearing; Semi automatic and presettable tare; Scale switch; Setting of outputs activation thresholds.

DGT20 and DGT20AN models: Reading of microvolts or ADC converter for all the channels; Message display; Printing; Setting of APW in counting mode; Simulation of key pressure;MODBUS serial protocol.

Analogue output proportional to the net or gross weight, either positive (in loading) or negative (in unloading).

More Information
CommunicationRS232, RS485, Profibus, 4-20ma / 0 - 10v
DisplayBright LED - 6 x 20mm Digits
Power Requirements12 Vdc to 24 Vdc power supply; 12Vdc power adapter included.
IP RatingNo Rating
