SPN750 Single Point Load Cell

• C3 precision class
• Off center load compensated
• Aluminium alloy construction
• IP67 protection
• Max. capacity: 750kg
• For platforms with dimensions up to 800 x 800 mm
• Shielded connection cable
• OIML and test certificates available upon request

• Minimum load cell verification interval: Vmin = EMax / 10.000-15.000
• Maximum number of verification intervals: nLC = 3000
• Sensitivity: 2mV/V ± 10%
• Temperature effect on zero:

  • from ±0,0093% F.S./10K to ±0,0140%
• Temperature effect on Full Span:

  • 0,0117% F.S./10K (-10°C/+20°C)
  • 0,0175% F.S./10K (+20°C/+40°C)
• Compensated Temperature Range: -10°C/+40°C
• Operating Temperature Range: -10°C/+50°C
• Creep at nominal load in 30 minutes: 0,01% F.S.
• Maximum excitation voltage without damage: 15 Vdc
• Input Resistance: 300..500 Ohm
• Output Resistance: 300..500 Ohm
• Insulation Resistance: >2000 MOhm
• Mechanical limit load in service: 150% F.S.
• Destructive load: 300% F.S.
• Deflection at nominal load: <0,5mm
• 6-wire shielded cable, 3m long, 5mm diameter

The CCATEX certificate makes the load cell suitable for use in hazardous areas with protection methods according to:

• ATEX II 1G Ex ia IIC T6 (Ta -20÷+40°C) TX (Ta -20÷+65°C) Ga
• ATEX II 1D Ex ta IIIC TX°C (Ta -20÷+40°C) TX°C (Ta -20÷+65°C) Da IP65.

The certificate includes the manual and the ATEX CE conformity declaration (available in EN, DE, FR, and IT).

IMPORTANT: the certificate refers to the single load cell. For systems with more load cells, it is necessary to order one certificate for each load cell.
